Displacement, Velocity, and Acceleration
Introduced| English | Meaning |
|---|---|
| distance/ˈdɪstəns/ | The total length of a path travelled. |
| position/pəˈzɪʃn/ | An object's location relative to a chosen reference point or coordinate system. |
| displacement/dɪˈspleɪsmənt/ | The straight-line change in position, including direction. |
| scalar/ˈskeɪlə/ | A quantity described by magnitude alone, with no direction. |
| vector/ˈvektə/ | A quantity with both magnitude and direction. |
| velocity/vəˈlɒsɪti/ | The rate of change of displacement. |
| average velocity/ˈævrɪdʒ vəˈlɒsɪti/ | The total displacement of an object divided by the elapsed time. |
| speed/spiːd/ | The distance travelled per unit time. |
| magnitude/ˈmæɡnɪtjuːd/ | The size or numerical value of a quantity. |
| instantaneous velocity/ˌɪnstənˈteɪnɪəs vəˈlɒsɪti/ | The velocity at one moment: the derivative of position, or the tangent gradient of a position-time graph. |
| acceleration/əkˌseləˈreɪʃn/ | The rate of change of velocity. |
One full lap — so how far from the start?
- A runner sprints one lap of a 400 m track and stops exactly where they began.
- Their distance 距离 travelled is $400\ \text{m}$. Their change in position is zero.
- Two honest answers to "how far?" — because one counts the path, the other counts the change in place.
- Kinematics needs both, and never mixes them up.
Distance vs displacement
- Distance (a scalar 标量) is the total path length — always positive, it only grows.
- Displacement 位移 (a vector 矢量) is the straight-line change in position 位置.
- We write it $\Delta x = x_f - x_i$ — final position minus initial position.
- On the lap, distance $= 400\ \text{m}$ but displacement $\Delta x = 0$.
A runner completes exactly one lap of a 400 m track. What is their displacement?
Difficulty 1/5 · 100 coins + a small bonus on first completion today
Displacement is the change in position. The runner ends where they started, so $\Delta x = 0$. The distance travelled is $400\ \text{m}$.
Velocity: how fast position changes
- Velocity 速度 is displacement per unit time — it carries a direction.
- Average velocity 平均速度: $\displaystyle v_{\text{avg}} = \frac{\Delta x}{\Delta t}$.
- Speed 速率 is the magnitude 大小 of velocity — a scalar, no direction.
- Drive 300 km in 5 h with detours: high average speed, but a small average velocity if you end up near home.
A cyclist has a displacement of $240\ \text{m}$ in $30\ \text{s}$. What is the average velocity, in $\tfrac{\text{m}}{\text{s}}$?
Difficulty 2/5 · 140 coins + a small bonus on first completion today
$v_{\text{avg}} = \dfrac{\Delta x}{\Delta t} = \dfrac{240}{30} = 8\ \tfrac{\text{m}}{\text{s}}$.
Instantaneous velocity
- Average velocity smears over a whole interval; instantaneous velocity 瞬时速度 is the value at one instant.
- It is what $\dfrac{\Delta x}{\Delta t}$ approaches as $\Delta t$ shrinks toward zero.
- On a position–time graph, it is the slope of the tangent at that point.
- A speedometer reads instantaneous speed — the size of the instantaneous velocity.
Acceleration: how fast velocity changes
- Acceleration 加速度 is the rate of change of velocity: $\displaystyle a_{\text{avg}} = \frac{\Delta v}{\Delta t} = \frac{v_f - v_i}{\Delta t}$.
- It is a vector, measured in $\tfrac{\text{m}}{\text{s}^2}$.
- Speeding up, slowing down, and turning are all accelerations — each changes the velocity vector.
- The units stack neatly: position $\text{m}$, velocity $\tfrac{\text{m}}{\text{s}}$, acceleration $\tfrac{\text{m}}{\text{s}^2}$.
Build the motion from u and a
Change the starting velocity and acceleration, and watch how the position and velocity graphs respond.
Acceleration is the rate of change of ____.
Difficulty 1/5 · 100 coins + a small bonus on first completion today
By definition $a = \Delta v / \Delta t$ — the change in velocity per unit time.
Select all the quantities that are vectors.
Difficulty 2/5 · 140 coins + a small bonus on first completion today
Displacement, velocity and acceleration all carry a direction. Distance and speed are scalars (magnitude only).
A negative acceleration does not always mean "slowing down". An object slows only when its acceleration points opposite to its velocity. If both are negative (e.g. falling faster downward), it is speeding up.
A negative acceleration always means the object is slowing down.
Difficulty 1/5 · 100 coins + a small bonus on first completion today
An object slows only when acceleration points opposite to velocity. A negative acceleration on a negative (downward) velocity speeds the object up.
A car speeds up from $8\ \tfrac{\text{m}}{\text{s}}$ to $20\ \tfrac{\text{m}}{\text{s}}$ in $4\ \text{s}$.
- $\Delta v = 20 - 8 = 12\ \tfrac{\text{m}}{\text{s}}$.
- $a = \dfrac{\Delta v}{\Delta t} = \dfrac{12}{4} = 3\ \tfrac{\text{m}}{\text{s}^2}$.
The acceleration points the same way as the velocity, so the car speeds up.
A car speeds up from $8\ \tfrac{\text{m}}{\text{s}}$ to $20\ \tfrac{\text{m}}{\text{s}}$ in $4\ \text{s}$. What is its acceleration, in $\tfrac{\text{m}}{\text{s}^2}$?
Difficulty 2/5 · 140 coins + a small bonus on first completion today
$a = \dfrac{v_f - v_i}{\Delta t} = \dfrac{20 - 8}{4} = 3\ \tfrac{\text{m}}{\text{s}^2}$.
Distance (scalar) counts the path; displacement $\Delta x = x_f - x_i$ (vector) counts the change in position. Velocity $= \Delta x / \Delta t$; speed is its magnitude. Acceleration $= \Delta v / \Delta t$ — how fast velocity changes, including turning.
Write from an acceleration of 4
- A cart speeds up from 6 m/s to 18 m/s in 3 s.
- Find the acceleration.
A cart speeds up from 6 m/s to 18 m/s in 3 s. What is its acceleration, in m/s squared?
12 divided by 3 is 4.
What is the acceleration?
Difficulty 1/5 · 100 coins + a small bonus on first completion today
The speed rises by 12 m/s in 3 s. Other options — 3 m/s squared (the lesson car); 12 m/s squared (the speed change used as the acceleration).
